The Centerforce(R) DFX(R) Clutch Series is SFI approved and brings together various reinforcements and patenteds technologies for a great race-inspired single disc clutch.
The Centerforce(R) DFX(R) Clutch Series is the competition-proven clutch package for select import and domestic applications. This DFX series is engineered for competition standards of quality and craftsmanship. The DFX series is aimed at high-end applications that continually demand increased integrity and holding-capacity. DFX scores big, not only with holding-capacity and strength, but also provides some of the best drivability from a race-inspired single disc clutch. The DFX series features the patented Centerforce centrifugal weight system (where applicable) and retains an easy pedal effort, thanks to Centerforce's patented ball bearing actuated diaphragm, for smooth engagements without detriment to the vehicle's release components. The Centerforce DFX performance clutch system is SFI approved for competition with Nodular Iron pressure plate rings and reinforcements designed to help prevent drive strap breakage and safety. Note: Due to the materials used, the DFX clutch series is more aggressive with less dampening; this can cause some additional drive train noise and/or chatter.
Application Summary:
| Year |
Make/Model |
| 1994-2005 |
Dodge Ram 2500 |
| 1994-2005 |
Dodge Ram 3500 |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
22, 22 |
| Clutch Bolt Type |
with Shoulder Bolt, with Shoulder Bolt |
| Clutch Disc Diameter |
12.25, 12.25 |
| Counterweight Assist |
Yes, Yes |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
8, 8 |
| Disc Material |
Cerametallic, Cerametallic |
| Disc Quantity |
1, 1 |
| Disc Type |
8-Paddle, 8-Paddle |
| Disc Type Sprung Solid |
Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/4, 1-1/4 |
| Input Spline Quantity |
10, 10 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Cerametallic Button Style Friction, Cast Iron Pressure Plate / Cerametallic Button Style Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
93.3 |
| Pilot Bushing Included |
Yes, Yes |
| Release Bearing Included |
Yes, Yes |
| Ring Gear O.D. |
15.625, 15.625 |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N, N |
| Tooth Quantity |
152, 152 |
| Torque Capacity |
900, 900 |
| Warranty Time |
12 |
| GTIN |
00788442037548 |
